Code:
- ES-20
ES-20 SMOKE DETECTOR SD-604PC
Color: White
Operating Voltage: DC:9V-35V
Standby Current: 55uA
Alarm Indication: Red LED
Alarm Current: 105±3dB
Reset: Power off or auto reset
Sensitivity: 0.5db/m
- SMT adopted, High stability, Low standby current, Anti-RFI & Anti-EMI 9-35VDC Voltage, Duel LED for 360 visual, Flashing LED power indicator
Description
Reviews (0)
Related products
ES-02 FIRE GLOVES BLUE
Color: Blue
Reflector: Yellow + Silver
Sizes: Free size
- Ordinary fire gloves with flame-retardant, acid, heat-resistant
- Comfortable layer with flame-retardant properties fabrics
- Fireman can wear this gloves to protect hand, wrist and against scratches, cut
- With reflective strap to protect yourself easily
ES-12 (2,4,8,16 ZONE) CONVENTIONAL FIRE ALARM PANEL
Parameters: 37 x 44 x 10 cm
AC Power: 90 to 270VAC, 50Hz/60Hz
Power Supply Rating: 3 Amps @ 24VDC
Standby Detector: 4mA maximum
Maximum Detector: 30 detectors
Fault Relay Rating: 2A & 30VAC, resistive
Alarm Relay Rating: 2A & 30VAC, resistive
Features: Built-in alarm horn, easy to install and expand, long term usage, built-in imported chips for more stable and durable
• Two, four, eight, sixteen zone style B (Class B) initiating device circuits (IDCs), all zones accept two-wire smoke detectors and any normally-open contact devices.
• Two supervisory Input with DC12V output, ideal to connect security alarm devices.
• Three general alarm, trouble and supervisory, form a relay output.
• One, two, four built-in sound output, style Y (Class B) notification appliance (Signal) circuits (NACs), NACs may be programmed: Silenceable or non-silenceable.
• 3.0 amps of total system power. Resettable DC24V & non- resettable DC24V output.
• Zone input short circuit can be set to “Alarm” or “Fault” mode.
• RS485 Communication port (optional).
• Automatic/Manual mode can be programmed.
• Disable/Enable control per zone (IDC) can be programmed.
• Disable/Enable sound output(NACs) can be programmed.
ES-13 HANDLE ALARM
Color: Red
Material: ABS plastic
Sizes: 140 x 104 x 45 (mm)
Operating Voltage: 9-28VDC Volts
Weight: 220g
Operating Temperature Range: -10°C to 50°C (14F to 122F)
- The conventional manual call point designed for conventional fire alarm system for reporting fire or emergency condition by its push in/pull down
