Parameters: 37 x 44 x 10 cm
AC Power: 90 to 270VAC, 50Hz/60Hz
Power Supply Rating: 3 Amps @ 24VDC
Standby Detector: 4mA maximum
Maximum Detector: 30 detectors
Fault Relay Rating: 2A & 30VAC, resistive
Alarm Relay Rating: 2A & 30VAC, resistive
Features: Built-in alarm horn, easy to install and expand, long term usage, built-in imported chips for more stable and durable
• Two, four, eight, sixteen zone style B (Class B) initiating device circuits (IDCs), all zones accept two-wire smoke detectors and any normally-open contact devices.
• Two supervisory Input with DC12V output, ideal to connect security alarm devices.
• Three general alarm, trouble and supervisory, form a relay output.
• One, two, four built-in sound output, style Y (Class B) notification appliance (Signal) circuits (NACs), NACs may be programmed: Silenceable or non-silenceable.
• 3.0 amps of total system power. Resettable DC24V & non- resettable DC24V output.
• Zone input short circuit can be set to “Alarm” or “Fault” mode.
• RS485 Communication port (optional).
• Automatic/Manual mode can be programmed.
• Disable/Enable control per zone (IDC) can be programmed.
• Disable/Enable sound output(NACs) can be programmed.
